14+ Years of Industrial Coating Heritage
High Bond Powder Coating operates a dedicated manufacturing facility in GIDC Vapi, Gujarat, backed by 14+ years of hands-on industrial finishing experience under Universal Metal.
14+ Years
Operational Heritage
Universal Metal Legacy
Precision Chemistry Rooted in Experience
Originating under Universal Metal, High Bond Powder Coating was established to deliver specialized thermoset powder coatings with uncompromising batch repeatability for India's leading manufacturers.
Our Vapi manufacturing plant is equipped with computerized automated extruders, high-speed micronizing mills, and an ISO 9001:2015 certified quality control lab.
Quality Mission
Zero batch-to-batch color variance (ΔE < 1) and 24-hour sample dispatch commitment.
Infrastructure
Dedicated production lines for Pure Polyester, Epoxy-Polyester Hybrids, and Pure Epoxy.
10-Point Quality Testing Equipment
Technical performance testing evaluates the physical and chemical durability of industrial coatings to ensure long-term surface protection. These standardized assessments verify that the cured film complies with strict industrial quality benchmarks.
Appearance & Film Characteristics
Dry Film Thickness (DFT) : ISO 2808
An electronic gauge measures the cured coating thickness in microns (µ). The result ensures uniform coverage and optimal protective properties.
Gloss at 60° : ASTM D 523 standard
A light beam reflects off the surface at a 60-degree angle. The percentage result classifies the coating shine from matte to high-gloss.
Particle Size Distribution : Under 63 µ
Sieving measures the percentage of fine powder particles. The result ensures smooth powder fluidization and consistent electrostatic spraying.
Mechanical Durability & Strength
Impact D/R (Direct/Reverse) : ASTM D 2794 standard
A standard weight drops from varying heights to deform the panel. The result (in Kgcm) indicates resistance to sudden cracking or chipping.
Adhesion (GT=0) : ASTM D 3359
A grid is cut into the film and pulled with specialized tape. A GT=0 rating signifies perfect adhesion with zero coating detachment.
Cupping Test : ISO 1520 standard
A spherical punch slowly pushes into the back of the metal panel. The result measures the depth in millimeters (mm) tolerated before the film fractures.
Flexibility : Visual bend test
Evaluated through a Visual bend test. The panel bends over a cylindrical mandrel of a specific millimeter (mm) radius. The result confirms the coating stretches without cracking.
Hardness & Environmental Resistance
Scratch Hardness : ASTM D 5178 standard
A weighted stylus moves across the coated surface. The result records the weight in kilograms (Kg) required to cut through to the metal substrate.
Pencil Hardness : 2H
Calibrated drawing leads are pushed into the coating at a 45-degree angle. A successful 2H result guarantees excellent daily scratch resistance.
Salt Spray : ASTM: B117/1000+hrs
Panels endure a continuous, heated salt fog environment. The result tracks the hours and minutes (Hrs.min) the coating resists rust and blistering.
Visit Our Facility or Inquire Direct
Reach our technical team directly for factory tours, custom color matching, or volume pricing.
